If your device belongs to the Communications and CDC Control device class, Usbser.sys is loaded automatically.You do not need to write your own INF to reference the driver. The driver is loaded based on a compatible ID match similar to other USB device class drivers included in Windows.
In the Windows® XP Control Panel, open 'Sounds and Audio Devices Properties' Under the 'Volume' tab, verify that 'Bose USB Audio' is the connected USB device; Under 'Speaker settings', click the 'Advanced' button to open 'Advanced Audio Properties' In the 'Speaker setup' drop-down list, select '5.1 surround sound speakers' Click 'Apply'.

If your Bluetooth does not seem to discover your devices, then it is likely that the problem has something to do with your drivers. To fix this issue, we recommend reinstalling your Bluetooth drivers by following the steps below: Go to your taskbar, then right-click the Windows icon. From the list, select Device Manager. To use Music Share with your Bose QC 35 II, start by pairing the headphones to your mobile device. Launch the Bose Connect App and tap the Music Share icon in the bottom left corner (it’s a picture of two headphones side-by-side). Then, tap the button labelled “Find a Headphone.” Turn on your second pair of Bose headphones.

Your SoundLink® speaker is designed to provide years of service with a wide range of mobile devices. Periodic updates may be needed to keep your speaker compatible with products released after your speaker's manufacture date.

All details and instructions are featured below. For more information, see our FAQs

300 MHz processor (1 GHz for Vista or Windows 7) 32 or 64 bit
128 MB RAM (Windows XP); 512 MB (Vista Home Basic); 1 GB (other Vista editions and Windows 7 32 bit); 2 GB (Windows 7 64 bit)
Internet connection
30 MB available hard disk space
USB 1.1, 2.0 or 3.0 port

OS v10.5 (Leopard), v10.6 (Snow Leopard) or OS v10.7 (Lion)
Intel-based processor
512 MB RAM (Leopard); 1 GB (Snow Leopard)
Internet connection
40 MB available hard disk space
USB 1.1, 2.0 or 3.0 port

First, download the Bose Bluetooth® speaker update application to your computer.

Note for Windows users:
If you have multiple user accounts on your computer, you may be prompted to input administrator credentials in order to run the application.

Once downloaded, the application will prompt you to connect your speaker to your computer with a micro USB cable.

Please make sure the SoundLink® speaker is plugged in using the AC power adapter before running the update application.

If Save, select a location for saving the file (Bose_BLUETOOTH_Speaker_Update.exe). Then start the application from your hard drive and follow the prompts to perform the update.

Wait for your computer to download the file. It will appear on your desktop as a hard drive icon

A window should open. Drag the updater file to the desktop as indicated. (If the window doesn't open, double-click the icon.)

Run the update application from your desktop and follow the prompts to perform the update.

What is the purpose of the SoundLink ® Wireless Mobile speaker firmware update application?

This application allows for a simple, immediate software download directly to your computer and into the SoundLink ® speaker.

Why might I need to upgrade my speaker firmware?

Periodic software updates may be needed to keep your SoundLink ® speaker compatible with mobile devices released after your speaker's manufacture date.

Can this update be accomplished on either a PC or a Mac?

Yes. The PC or Mac used for the update must meet the minimum system requirements found on the download site.

How do I connect my SoundLink ® speaker to my PC/Mac?

You can use any USB to micro-USB cable that you may have, usually supplied with a digital camera or GPS.

Will this update affect my computer in any way?

While the application is running, it will create and utilise temporary working files. When the application has finished and closed, it will remove all temporary working files, leaving behind the driver and the downloaded application file (Windows machines only). The application file can be deleted from your computer after the update is complete, but we recommend leaving the driver installed on your computer to make future upgrades easier.

How long will the update take?

The update may take as long as five minutes to complete.

5USB from Computer
7Step by Step
- 7.2USB and Channel 4/5 Analog at the same time
- 7.6No Reverb from USB

T1 USB Connection

Connection from Computer to T1 ToneMatch^® Audio Engine

Here is an excerpt from the T1 ToneMatch® Audio Engine Owner's Guide (62 pages)

Here is a close up of the ends of the cable.

Live Application of USB in the T1 ToneMatch^® Audio Engine

Hilmar-at-Bose talks about the USB interface^[1]

Firstly, the T1 ToneMatch Audio Engine is designed as a convenient and powerful interface for a live musician. We try to put many useful controls directly at your finger tips so you can operate them while your playing or between songs. This basic idea has also influenced how we've implemented USB audio streaming. We try to accommodate the most common use cases (background tracks, DJ, quick recording) with the least amount of hassle & configuration work, even if that makes less common uses cases more difficult to accommodate.

USB audio in general

Hilmar-at-Bose talks about the USB interface^[2]

When you plug in the T1 ToneMatch^® Audio Engine into your PC it will appear to the PC as a USB sound card (USB audio device in Windows). You can play and record audio just like with any other soundcard, i.e. if you use for example Windows Media Player to play a song, the audio will be routed via USB to the T1 ToneMatch Audio Engine.

On the T1 ToneMatch^® Audio Engine you can decide where you want it. You can route it either to the master (e.g. when using the PC to play background tracks) or into channel 4/5 to process it to your hearts content.

The T1 ToneMatch Audio Engine can also send audio back to the PC. You can select what you want to send. It can be either channel (1,2,3,4/5) or Aux or Master. For example you can make a little submix on the AUX bus and record that with for example Windows Sound Recorder or Audacity.

Here is an excerpt from page 30 of the ToneMatch® Audio Engine Owner's Guide

USB from T1® to PC (Computer)

USB to PC
Factory settings, the default
Set output to Left
Set output to Right
This shows the result of sending T1® Channels 1 and 2 to USB LEFT and RIGHT
Here is how you can send Master and Aux outputs to USB LEFT and RIGHT

USB from Computer

USB from PC to Master

The factory setting for USB from PC is to route the Computer's Left and Right Outputs to Master Output and you control all of the sound from the computer.
You can route one or both channels to Channel 4/5 and this gives you local control of Presets, zEQ, ParaEQ, Effects and volume.

Setting USB from PC to Channel 4/5

You can connect your Computer to your T1^® and send one or both stereo channels to to Channel 4/5. This allows you to control the sources applying ToneMatch® Presets, zEQ, ParaEQ, Effects and volume using the Channel 4/5 Vol control.

Video

Step by Step

Turn the Rotary Selector to Global section and Prefs
Press the first button, Menu
Turn the Menu to USB from PC, Press
By default the USB from PC Left and Right channels are routed to the Master Output and you control all of the sound from the computer.
You can route one or both channels to Channel 4/5 and this gives you local control of Presets, zEQ, ParaEQ, Effects and volume.
Press the middle button Left to change the routing of the Left channel
Turn to select Channel 4/5, Press
If you want to route the the Right Channel to Channel 4/5
Press the right button Right to change the routing of the Right channel
Turn to select Channel 4/5, Press
Here is the final result

Monitor input levels

Turn the Rotary Selector to Global section and Prefs
Press the first button, Menu
Turn the Menu to Input Level.
Press the first button to view the Input Levels

USB and Channel 4/5 Analog at the same time

You can connect the USB input to T1^® Channel 4/5 for a stereo source (computer) AND an analog input to T1^® Channel 4/5 at the same time. While it is unlikely you would play both sources simultaneously, you can raise and lower the outputs at the source. This allows you to control the sources applying ToneMatch® Presets, EQ, and volume using the Channel 4/5 Vol control.

See: Settings USB from Computer to Channel 4/5 (above) for USB setup and Analog Connection below.

Analog Connection

Latency and Digital Audio Workstation

USB audio requires a fairly complicated driver stack and hence we have decided to operate with the Windows standard drivers. That's fairly rugged but also not particularly fast, so processing sounds in real time on the PC and sending back to the T1 may or may not work depending how the computer is configured, what operating system is running, and what other processes are going on at the same time. See also: Latency and The L1®

Digital Media players and USB host

The T1 ToneMatch Audio Engine is only a USB client and requires a USB host (= PC). That means you cannot connect an MP3 player directly to the T1 digitally. The best way to connect is analog through Ch 4/5.

Stereo or Mono

Hilmar answers ^[3]

Tom Munch asked: Can channels 4 & 5 be assigned separately to the Aux & Master outs to send to 2 L1's?

Not really. 4/5 are immediately summed to mono and treated the always the same. You could route the left USB channel to the master, and the right USB channel to 4/5, turning the 4/5 channel volume all the way down and using a pre-fade AUX feed for 4/5 to get it out the Aux.

That's certainly a little convoluted but would enable you to route a USB source to two different L1s.

No Reverb from USB

From page 30 of the T1 ToneMatch® Audio Engine Owner's Guide (62 pages)

Work Around

Hard wire Master Output to Channel 4 input
Channel 4 Aux Level 100% | Tap: Pre
Channel 4 Vol off (Mute too to be safe but not critical)
Prefs: USB to PC set to Aux

ASIO

From Chuck-at-Bose

I'd like to offer some clarification that may or may not help. Sound cards, including the T1, depend upon 'drivers' to do what they do. ASIO/WDM/MME aren't really drivers, but driver access protocols. ASIO usually results in the lowest amount of round-trip latency (all things being equal) because, unlike the others, it bypasses the operating system (e.g. Windows) kernel...

FWIW, I have used the T1 very successfully for recording and playback with SONAR 8 PE on my PC using WDM and ASIO. I got the best results (lowest latency, fewest dropouts, etc.) using ASIO4all. Given the zillions of variables among hardware configs, operating systems, etc., your mileage may vary. I think it's worth stating that the T1 excels as an interface for an L1 system and though it happens to work great as a basic sound card (record/playback/re-amp, etc.), there are lots of soundcards out there that do more than these basics. Their value, in my experience, is commensurate with their price tag...
